CT MORSE TAPER WITH TANG

Item No.: CO16727734
Send Enquiry

1.High quality elastic steel material with long use time.
2.Shank of the R8 Taper Collet Chuck, R8 Taper.
3.Suitable Collet:ER11/ER16/ER20/ER25/ER32/ER40
4.The precision little than 0.01mm with balance 10,000rpm. Higher precision also can be made by your demand.
5.Holder hardness:48-55HRC
6.The protrusion length is difference from 20mm to 200mm.
7.Suitable NUT & Wrench is also upon request.

GD-0088	CT MORSE TAPER WITH TANG
Order NO. CT×MS.NO.T-L1	L	D	D1	Wt（kg）
Order NO. CT×MS.NO.T-L1	L	D	D1	Wt（kg）
CT40×MS1-45	113.25	25	44.45	1.30
CT40×MS2-63	131.25	32	44.45	1.70
CT40×MS3-75	143.25	40	44.45	2.00
CT40×MS4-100	168.25	48	44.45	2.50
CT45×MS1-40	122.55	25	57.15	2.70
CT40×MS2-50	132.55	32	57.15	3.80
CT40×MS3-73	155.55	40	57.15	4.20
CT40×MS4-95	177.55	48	57.15	4.60
CT40×MS5-125	207.55	61	57.15	5.50
CT50×MS1-40	141.6	25	69.85	4.00
CT50×MS2-50	151.6	32	69.85	4.00
CT50×MS2-135	236.6	32	69.85	5.00
CT50×MS3-63	164.6	40	69.85	4.50
CT50×MS3-150	251.6	40	69.85	5.50
CT50×MS4-85	186.6	48	69.85	4.80
CT50×MS5-105	206.6	61	69.85	5.20
