CNC Tool Series
ISO30 ISO40 ISO50 Toolholder
- Item No.: CO16712734
- Send Enquiry
| Taper | D1 | g | d1 | D5 | L1 | f | e | b | a |
|---|---|---|---|---|---|---|---|---|---|
| ISO30 | 31.75 | M12 | 13 | 50 | 68.4 | 16.2 | 8 | 16.1 | 1.6 |
| ISO40 | 44.45 | M16 | 17 | 63 | 93.4 | 22.5 | 10 | 16.1 | 1.6 |
| ISO50 | 69.85 | M24 | 26 | 97.5 | 126.8 | 35.3 | 12 | 25.7 | 3.2 |
