1.Products name : ER milling chuck set
2.1 set included : 1 collet chuck,1 clamping nut,full set of collets and 1 spanner
3.Packed in a wooden socket or alum box
4.We can assemble the set as per customer's requirements.
5.Please notify the thread of collet chuck draw bar and the specification of collets(metric or inch)
6.Please notify the length of straight shank and dia.
7.We are glad to supply collets and chucks with different shank and quantities according to your requirement.
8.Feature:Improve the hardness and endurance of the surface
Cleaness better,Accuracy stable
Surface more smooth,Feel comfortable,Appearance nice
9.Brand : GD-TOOLS
ER MILLING CHUCK SET | ||||||
Order No. | Hole size | Pcs/set | Shank | |||
in | mm | |||||
ER16-8in(mm) | 3/32 1/8 3/16 7/32 1/4 5/16 11/32 3/8 |
2 3 4 5 6 7 8 10 | 8 | R8 MS2-MS6 ISO3O ISO40 ISO50 1/2" str.sh 5/8" str.sh 3/4" syr.sh 1" str.sh 1-1/4" str.sh |
||
ER25-6in(mm) | 1/8 3/16 5/16 3/8 1/2 5/8 | 4 6 8 10 12 16 | 6 | |||
ER25-10in(mm) | 3/32 1/8 3/16 1/4 5/16 3/8 7/16 1/2 9/16 5/8 |
3 4 5 6 8 10 12 14 15 16 | 10 | |||
ER32-6in(mm) | 1/4 5/16 3/8 1/2 5/8 3/4 | 6 8 10 12 16 20 | 6 | |||
ER32-12in(mm) | 3/32 1/8 3/16 1/4 5/16 3/8 7/16 1/2 9/16 5/8 11/16 3/4 |
3 4 5 6 8 10 12 14 15 16 18 20 | 12 | |||
ER40-8in(mm) | 1/8 1/4 3/8 1/2 5/8 3/4 7/8 1 | 3 5 8 12 15 18 22 26 | 8 | |||
ER40-15in(mm) | 1/8 3/16 1/4 5/16 3/7/16 1/2 9/16 5/8 11/16 3/4 13/16 7/8 15/16 1 |
3 4 5 6 8 10 12 14 15 16 18 20 22 24 26 |
15 | |||
Thread of draw bar | ||||||
Taper of collet chuck | Thread of draw bar | |||||
R8 | 7/16" -20UNF | |||||
7:24 30 | M12×1.75 | 1/2" -13UNC | ||||
7:24 40 | M16×.0 | 5/8" -11UNC | ||||
7:24 50 | M24×.3.0 | 1" -8UNC | ||||
MS2 | M10×.1.5 | 3/8" -16UNC | ||||
MS3 | M12×.1.75 | 1/2" -13UNC | ||||
MS4 | M16×.2.0 | 5/8" -11UNC | ||||
MS5 | M20×.2.5 | 3/4" -10UNC | ||||
MS6 | M24×.3.0 | 1" -8UNC |
